Seeed Studio XIAO nRF52840 Sense Plus Bluetooth Development Board
Seeed Studio XIAO nRF52840 Sense Plus Bluetooth Development Board
Shipping calculated at checkout.
The Seeed Studio XIAO nRF52840 Sense Plus pairs Nordic's low-power nRF52840 MCU with an onboard 6-axis IMU and a PDM microphone, giving a single tiny board both motion and audio sensing without extra breakout modules. Bluetooth Low Energy 5.4 with a built-in antenna and NFC support covers most short-range wireless needs out of the box.
Deep sleep draws just 5μA, and onboard Li-ion charging makes it straightforward to build genuinely battery-run wearables and sensor nodes that last. The 21x17.8mm board keeps 20 GPIOs accessible via both 2.54mm headers and 1.27mm castellated pads, so it works equally well breadboarded or reflow-soldered onto a custom PCB. Development is supported through Arduino, CircuitPython, MicroPython, and TinyML toolchains.
- Nordic nRF52840 MCU, 64MHz with FPU
- Onboard 6-axis IMU and PDM microphone
- Bluetooth LE 5.4 with NFC support
- 5μA deep sleep, Li-ion charging onboard
Well suited to Indian makers building wearables, health-monitoring devices, or low-power sensor networks.
Country of origin: China
