L293D Motor Driver Board
Drive up to 4 DC motors or 2 stepper motors simultaneously with this versatile L293D Motor Driver Shield. Built around the reliable L293D dual H-bridge IC, this board is the go-to solution for robotics, automation, and motor control projects.
Specifications
| Driver IC | L293D Dual H-Bridge (2 ICs onboard) |
| DC Motor Channels | Up to 4 bidirectional DC motors |
| Stepper Motor Channels | Up to 2 stepper motors (unipolar/bipolar) |
| Servo Motor Outputs | 2 dedicated servo connections (PWM) |
| Motor Supply Voltage | 4.5V - 25V (external supply supported) |
| Logic Supply Voltage | 5V (from Arduino or external) |
| Per-Channel Current | 600mA continuous / 1.2A peak per channel |
| Speed Control | PWM-based variable speed control |
| Direction Control | Full forward, reverse, brake, and coast |
| Interface | Stacks directly onto Arduino Uno/Mega |
| Protection | Kickback protection diodes built-in |
| Board Dimensions | Approx. 68mm x 55mm |
| Connector Type | Screw terminals for motor and power connections |
| Compatibility | Arduino Uno, Mega, Nano (with jumper wires), and compatible boards |
| Library Support | Adafruit Motor Shield Library (AFMotor) |
| Type | Motor Driver Shield / Expansion Board |
| Origin | Original/Authentic |
| Warranty | |
| Support | Email & WhatsApp reliable |
Key Features
- 4-Channel DC Motor Control: Drive up to four DC motors independently with full directional and speed control using PWM signals.
- Dual Stepper Motor Support: Control two unipolar or bipolar stepper motors for precision positioning in CNC, 3D printing, or robotic arm applications.
- 2 Servo Motor Outputs: Dedicated servo headers connected directly to Arduino's high-resolution PWM pins for smooth, accurate servo control.
- Arduino Shield Form Factor: Plugs directly onto Arduino Uno or Mega - no breadboard wiring or complex hookups needed. Stack and go.
- Separate Motor Power Supply: Supports an external power source for motors (up to 25V), keeping motor noise isolated from the Arduino's logic supply.
- Built-in Flyback Diodes: Onboard protection diodes safeguard the driver ICs from voltage spikes generated by inductive motor loads.
- PWM Speed Control: Smooth, variable speed control across all motor channels for precise movement and gradual acceleration/deceleration.
- Screw Terminal Connections: Secure, vibration-resistant screw terminals for motor and power wires - ideal for mobile robots and moving platforms.
- Adafruit AFMotor Library Compatible: Works seamlessly with the well-documented Adafruit Motor Shield library, making coding fast and beginner-friendly.
- Compact & Stackable Design: Low-profile board that sits neatly on your Arduino, leaving room for additional shields or sensor connections.
Why Choose This L293D Motor Driver Board?
- 100% authentic from trusted suppliers - verified quality components
- Expert technical support included - get help with wiring, code, and troubleshooting
- Beginner-friendly plug-and-play design eliminates complex wiring
- Proven reliability in thousands of robotics and automation projects worldwide
- Comprehensive library support reduces development time from hours to minutes
Project Ideas
- Line-Following Robot: Combine with IR sensors and an Arduino to build an autonomous line-tracking robot with precise motor control and smooth turns.
- Obstacle-Avoiding Robot: Pair with an ultrasonic sensor (HC-SR04) to create a smart robot that detects and navigates around obstacles in real time.
- Bluetooth/WiFi Controlled Car: Connect an HC-05 Bluetooth module or ESP8266 to build a smartphone-controlled RC car with variable speed and steering.
- CNC Plotter or Drawing Machine: Use the stepper motor channels to drive a 2-axis pen plotter that draws images and text from digital files.
- Automated Plant Watering System: Drive a small water pump motor to create a soil-moisture-triggered irrigation system for your garden or indoor plants.
- Robotic Arm
