DS1307 AT24C32 RTC Module - Real-Time Clock with EEPROM for Arduino & Microcontrollers
Keep your projects perfectly on time with the DS1307 AT24C32 RTC Module from The Tech Depot, Bengaluru. This compact, reliable real-time clock module combines the DS1307 RTC chip with an AT24C32 32Kbit EEPROM, giving you accurate timekeeping and onboard non-volatile data storage over the I2C interface. Ideal for data loggers, alarm systems, attendance trackers, and any application requiring persistent date/time tracking - even during power outages thanks to its CR2032 battery backup. Fast shipping across India with expert technical support included.
Specifications
| RTC Chip | DS1307 (I2C Real-Time Clock) |
| EEPROM | AT24C32 - 32Kbit (4KB) Non-Volatile Memory |
| Communication | I2C (TWI) Interface - SDA & SCL |
| Operating Voltage | 3.3V - 5V DC |
| Timekeeping | Seconds, Minutes, Hours, Day, Date, Month, Year (with leap-year compensation up to 2100) |
| Clock Format | 12-hour (AM/PM) or 24-hour selectable |
| Battery Backup | CR2032 coin cell socket (battery may or may not be included) |
| Oscillator | 32.768 kHz crystal (onboard) |
| Square Wave Output | Programmable - 1Hz, 4.096kHz, 8.192kHz, or 32.768kHz |
| I2C Address (RTC) | 0x68 (fixed) |
| I2C Address (EEPROM) | 0x50 - 0x57 (configurable via A0, A1, A2 pads) |
| Board Dimensions | Approx. 28mm x 27mm x 8.4mm |
| Mounting | 4 mounting holes for secure installation |
| Pin Header | SDA, SCL, VCC, GND, SQ (square wave output), DS (optional DS18B20 temperature sensor header) |
| Compatibility | Arduino, ESP8266, ESP32, Raspberry Pi, STM32, PIC, and all I2C-capable microcontrollers |
| Type | Clock / Timing Module |
| Origin | Original / Authentic |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Key Features
- Accurate Timekeeping: DS1307 maintains seconds, minutes, hours, day, date, month, and year with automatic leap-year correction through 2100.
- Battery Backup: CR2032 coin cell keeps the clock running for years even when main power is disconnected - no time resets on power cycles.
- 32Kbit EEPROM Onboard: AT24C32 provides 4KB of non-volatile storage for logging data, storing calibration values, or saving configuration settings.
- Simple I2C Interface: Only two data lines (SDA & SCL) needed - easily connect multiple I2C devices on the same bus.
- Wide Voltage Compatibility: Works seamlessly with both 3.3V and 5V logic-level microcontrollers.
- Programmable Square Wave Output: Generate precise clock signals at 1Hz, 4.096kHz, 8.192kHz, or 32.768kHz for timing applications.
- Optional Temperature Sensor Header: Dedicated DS pin for adding a DS18B20 temperature sensor directly on the module.
- Compact & Mountable: Small form factor with four mounting holes for easy integration into enclosures and project boards.
- Extensive Library Support: Compatible with popular Arduino libraries like RTClib, DS1307RTC, and Wire - get running in minutes.
Why Choose This RTC Module?
- 100% authentic DS1307 and AT24C32 ICs sourced from trusted suppliers
- Dual functionality - real-time clock plus EEPROM storage on a single compact board
- Plug-and-play with Arduino IDE using widely available libraries and example code
- 1-5 day shipping, 7-8 day delivery from our Bengaluru warehouse to most locations across India
- Expert technical support to help you with wiring, code, and troubleshooting
Wiring Guide (Arduino UNO)
| Module Pin | Arduino UNO Pin |
| VCC | 5V |
| GND | GND |
| SDA | A |
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
