ARDUINO MKR WAN 1300 (LORA CONNECTIVITY)
ARDUINO MKR WAN 1300 (LORA CONNECTIVITY)
ARDUINO MKR WAN 1300 (LoRa Connectivity)
Build long-range, low-power IoT networks with the Arduino MKR WAN 1300. Powered by the SAMD21 Cortex-M0+ microcontroller and the Murata CMWX1ZZABZ LoRa module (based on the SX1276 transceiver), this compact board enables wireless communication over distances up to 10+ km in open terrain - ideal for smart agriculture, environmental monitoring, asset tracking, and smart city applications. Available now from The Tech Depot, Bengaluru, with fast shipping, 7-day warranty on manufacturing defects, and dedicated technical support.
Key Specifications
| Microcontroller | SAMD21 Cortex-M0+ 32-bit ARM (48 MHz) |
| LoRa Module | Murata CMWX1ZZABZ (Semtech SX1276) |
| Connectivity | LoRa / LoRaWAN (868 MHz / 915 MHz regional bands) |
| Operating Voltage | 3.3V |
| Input Voltage (USB) | 5V |
| Battery Connector | Li-Po single cell 3.7V (JST PH connector, on-board charging) |
| Digital I/O Pins | 8 (all PWM capable) |
| Analog Input Pins | 7 (8/10/12-bit ADC) |
| Analog Output Pins | 1 (10-bit DAC) |
| Flash Memory | 256 KB |
| SRAM | 32 KB |
| Communication | UART, SPI, I2C |
| Board Dimensions | 67.64 mm x 25 mm |
| Weight | ~32 g |
| Form Factor | Arduino MKR standard |
| Crypto Chip | ATECC508A (hardware-based secure authentication) |
| USB Connector | Micro-USB (programming & power) |
| Type | IoT Development Board - LoRa |
| Origin | 100% Original / Authentic Arduino |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Why Choose the Arduino MKR WAN 1300?
- Extreme Range: LoRa technology delivers wireless communication over 10+ km in rural areas and several km in urban environments - far beyond Wi-Fi or Bluetooth.
- Ultra-Low Power: Designed for battery-operated deployments; the board features deep sleep modes and efficient power management for months-long operation on a single Li-Po cell.
- LoRaWAN Ready: Fully compatible with LoRaWAN networks (The Things Network, Chirpstack, etc.) for cloud-connected IoT at scale using the MKRWAN library.
- Hardware Security: On-board ATECC508A crypto chip provides secure key storage, mutual authentication, and encrypted communication for production-grade deployments.
- Compact MKR Form Factor: At just 67.64 x 25 mm, it fits into enclosures, wearables, and space-constrained sensor nodes with ease.
- Arduino Ecosystem: Program with the familiar Arduino IDE, access thousands of libraries, and leverage extensive community documentation and tutorials.
- MKR Shield Compatibility: Stack with MKR shields - MKR ENV Shield, MKR GPS Shield, MKR Relay Proto Shield, MKR Connector Carrier - to rapidly prototype complete solutions.
- On-Board Battery Charging: Connect a Li-Po battery directly; the board charges it automatically via USB, enabling seamless portable and remote deployments.
- 100% Authentic Arduino: Sourced directly from authorized distributors with full authentication verified.
- Fast Shipping from Bengaluru: 1-5 day shipping, 7-8 day delivery across India; same-day dispatch within Bengaluru.
Feature Highlights
- Murata CMWX1ZZABZ module combines a proven LoRa transceiver with an STM32L0 co-processor for reliable RF performance
- Supports multiple LoRaWAN frequency plans (EU868, US915, AU915, AS923, etc.) for global deployment
- 12-bit ADC and 10-bit DAC for precise analog sensor interfacing
- All 8 digital pins support PWM output for motor control, LED dimming, and actuator driving
- UART, SPI, and I2C interfaces for connecting GPS modules, OLED displays, environmental sensors, and more
- Native USB port for serial communication, debugging, and firmware updates - no external programmer needed
- Low-power RTC for timed wake-up and scheduled data transmission
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
