Arduino CNC Shield

The Arduino CNC Shield is a arduino + microcontroller component used by makers, students and engineers for electronics and embedded-systems projects.

Specifications

• Type: CNC Motor Driver Shield (Expansion Board)
• Compatible Board: Arduino Uno / Arduino Uno R3
• Firmware Support: GRBL 0.9 / GRBL 1.1 (open-source CNC controller)
• Stepper Driver Slots: 4 (X, Y, Z + 4th cloned axis A)
• Compatible Drivers: A4988 / DRV8825 / TMC2208 (pololu-style modules)
• Stepper Motor Support: 2-phase 4-wire stepper motors (NEMA 17 recommended)
• Axis Cloning: 4th driver can clone X or Y axis for dual-motor setups
• End Stop Pins: 6 (2 per axis - min and max limit switches)
• Spindle Enable Pin: Yes - PWM speed control output
• Coolant Enable Pin: Yes

Why Choose Arduino CNC Shield?

100% Authentic

GST Invoice - A GST invoice is included with every order.

Expert Support - Dedicated technical help on WhatsApp and email.

Pan-India Delivery - Shipped across Bengaluru, Delhi NCR, Hyderabad and all of India.

Trusted by Makers - Used by students, hobbyists and professionals nationwide.

Key Features of Arduino CNC Shield

• Plug-and-Play with Arduino Uno: Stacks directly onto the Uno header pins - no soldering, no breadboard wiring, no adapter cables required.
• 4 Independent Stepper Driver Slots: Control X, Y, and Z axes plus a 4th axis that can be configured as a clone of X or Y for dual-motor gantry systems.
• GRBL Firmware Compatible: Works seamlessly with GRBL, the industry-standard open-source CNC motion controller, accepting standard G-code commands.
• Flexible Microstepping Configuration: Onboard jumpers let you set microstepping resolution (full step through 1/16 step) independently for each axis for precision tuning.
• End Stop & Limit Switch Headers: Six dedicated pins (min and max for each axis) for homing switches and hard limits, enabling accurate machine calibration.
• Spindle & Coolant Control: Built-in PWM-capable spindle enable pin for controlling router/spindle speed and a coolant relay output for automated cooling systems.
• Wide Voltage Input (12V-36V): Separate motor power input supports a range of stepper motors and power supplies without stressing the Arduino's voltage regulator.
• Real-Time Control Pins: Dedicated header pins for Abort, Feed Hold, and Resume buttons give you physical emergency stop and pause capability.
• Universal Driver Compatibility: Accepts all pololu-format stepper drivers including A4988, DRV8825, and silent TMC2208 modules - swap drivers without changing hardware.
• Compact & Tech Depot India Design: 2-layer PCB with clean routing and proper ground planes ensures reliable signal integrity even during high-speed stepping operations.
• 100% authentic from trusted suppliers - no clones with poor solder joints or missing traces
• Ideal price-to-performance ratio for makers, students, and small workshop owners

Perfect For

• DIY CNC Router / Milling Machine: Pair with NEMA 17 stepper motors, lead screws, and a rotary tool to build a desktop CNC that cuts wood, acrylic,
• Rapid prototyping on top of an existing Arduino board without extra breadboard wiring
• Adding a specific capability (motor control, extra proto space, connectivity) to a maker project
• Classroom and workshop demonstrations of shield-based expansion

Arduino CNC Shield V3.0

Build your own CNC machine, laser engraver, or 3D printer with this dedicated CNC Shield designed to plug directly onto an Arduino Uno. Supports up to 4 stepper motor drivers (A4988/DRV8825), independent axis control, and GRBL firmware compatibility - everything you need to turn your Arduino into a powerful motion controller. Premium electronics from Tech Depot India, Bengaluru.
