Build powerful, responsive RC drones and multirotor aircraft with this perfectly matched motor and ESC combo from Tech Depot India, Bengaluru. The A2212 1400KV brushless DC motor paired with a Simonk 30A ESC delivers smooth, efficient thrust with rapid throttle response - ideal for quadcopters, hexacopters, and fixed-wing RC planes. Fast shipping across India with full technical support.

Specifications

Motor Model	A2212 1400KV Brushless DC (BLDC) Outrunner
KV Rating	1400 RPM/V
Motor Shaft Diameter	3.17 mm
Motor Weight	~52 g (without accessories)
Stator Diameter x Length	22 mm x 12 mm
No-Load Current	0.5 A @ 10 V
Max Continuous Current	12 A
Max Efficiency Current	4-10 A (>80% efficiency)
Compatible Battery	2S-3S LiPo (7.4 V-11.1 V)
Recommended Propeller	8x4.5 to 10x4.5 inch (3S), 10x4.5 to 11x4.7 inch (2S)
Max Thrust (approx.)	~800 g with 10x4.5 prop on 3S
ESC Model	Simonk 30A Brushless ESC
ESC Continuous Current	30 A
ESC Burst Current	40 A (10 seconds)
ESC Firmware	Simonk (ultra-fast throttle response)
ESC BEC Output	5 V / 2 A (Linear BEC)
ESC Input Voltage	2S-3S LiPo (7.4 V-11.1 V)
ESC Weight	~25 g
ESC PWM Frequency	High-frequency (Simonk optimized for multirotors)
Connector Type	3.5 mm bullet connectors (motor to ESC), standard servo lead (signal)
Origin	Original / Authentic

Why Choose A2212 1400KV BLDC Motor and Simonk 30A ESC for RC Drones?

100% Authentic

GST Invoice - A GST invoice is included with every order.

Expert Support - Dedicated technical help on WhatsApp and email.

Pan-India Delivery - Shipped across Bengaluru, Delhi NCR, Hyderabad and all of India.

Trusted by Makers - Used by students, hobbyists and professionals nationwide.

Key Features of A2212 1400KV BLDC Motor and Simonk 30A ESC for RC Drones

Matched Motor-ESC Combo: Pre-selected pairing ensures electrical compatibility - the 30A ESC comfortably handles the A2212's max draw of ~12A with generous headroom for safety and longevity.
1400KV Outrunner Motor: Optimized for medium-sized propellers (7-10 inch) on 2S-3S LiPo batteries, delivering excellent thrust-to-weight ratio for 450-550mm quadcopter frames.
Simonk Firmware ESC: Purpose-built firmware for multirotor applications with ultra-fast throttle response, active braking (complementary PWM), and smooth motor control - significantly outperforms generic ESC firmware in drone applications.
Built-in 5V BEC: The ESC's integrated Battery Eliminator Circuit provides 5V/2A output to power your flight controller and receiver directly - no separate voltage regulator needed.
High-Quality Construction: Motor features precision-balanced rotor, dual ball bearings for vibration-free operation, and N52-grade neodymium magnets for maximum efficiency.
Thermal Protection: ESC includes over-temperature and over-current protection to prevent burnout during aggressive flying or unexpected load conditions.
Plug-and-Play Connectors: Pre-soldered 3.5mm bullet connectors between motor and ESC for quick, secure connections - swap motors or ESCs in minutes.
Lightweight Design: Combined weight of only ~77g per motor-ESC unit keeps your all-up weight low for better flight time and agility.
Simonk Advantage: Standard ESCs introduce throttle lag that causes instability in multirotors. Simonk firmware eliminates this with high-frequency PWM and near-instant response, making your drone noticeably more stable and responsive.
Excellent Value: Get both motor and ESC in a single purchase at a bundled price - no guesswork on compatibility.
