Product Overview
The 74HC245 is a high-speed CMOS octal bus transceiver with 3-state outputs, designed for bidirectional data transfer between two buses. Ideal for microprocessor systems, memory interfaces, and digital logic applications requiring reliable bus buffering and isolation.
Key Specifications
| Parameter | Details |
| Type | Electronics Component - Logic IC |
| Function | Octal Bus Transceiver with 3-State Output |
| Package | DIP-20 / SOIC-20 |
| Supply Voltage | 2V to 6V (Typical 5V) |
| Logic Family | CMOS (High-Speed) |
| Data Transfer | Bidirectional (AB) |
| Output State | High Impedance (3-State) |
| Origin | Original/Authentic |
| Warranty | 7-day warranty on manufacturing defects |
| Technical Support | Email & WhatsApp 24/7 |
Features & Benefits
Bidirectional Data Transfer - Seamless A-to-B or B-to-A communication
3-State Output Control - Independent direction and output enable pins
Low Power Consumption - CMOS technology reduces heat and power draw
High-Speed Operation - Suitable for fast digital logic applications
Wide Supply Range - Works with 2V to 6V, compatible with multiple logic families
Compact Design - Space-efficient for PCB layouts
Industrial Grade - Reliable for professional and hobbyist projects
Applications
DIY Electronics & Hobbyists
- Microcontroller interfacing projects
- Digital logic experiments
- Bus buffering in breadboard circuits
- Learning embedded systems
Professional & Industrial
- Microprocessor-based systems
- Memory address/data bus buffering
- Industrial control systems
- Data acquisition modules
- PLC and automation equipment
Educational & Skill Development
- Electronics courses and labs
- Digital logic design projects
- Microprocessor architecture learning
- Circuit prototyping for students
Pin Configuration (DIP-20)
``` GND (Pin 10) VCC (Pin 20)DIR (Pin 1) - Direction Control
OE (Pin 19) - Output EnableA1-A8 (Pins 2-9, 11-18) - Bus A
B1-B8 (Pins 3, 4, 5, 6, 14, 15, 16, 17) - Bus B
```What's Included
1x 74HC245 Octal Bus Transceiver IC
Detailed datasheet (PDF) Pin configuration guideApplication notes and circuit examples
Technical support documentation
Why Choose The Tech Depot?
| Feature | Benefit |
| 100% Authentic | Sourced from authorized distributors with verification |
| Fast Shipping | 1-5 day shipping, 7-8 day delivery from Bengaluru warehouse to most of India |
| Expert Support | 24/7 technical assistance via Email & WhatsApp |
| Quality Assured | Tested components with 7-day warranty on manufacturing defects |
| Competitive Pricing | Best market rates with bulk discounts available |
| Easy Returns | 7-day return policy on defective items |
Frequently Asked Questions
Is this IC 100% authentic?
Yes, absolutely. All our components are sourced directly from authorized distributors with authentication verification and proper documentation.
What is the warranty coverage?
7-day warranty on manufacturing defects covering all manufacturing defects. If the IC fails due to manufacturing issues, we provide replacement or full refund.
How quickly will I receive my order?
Standard delivery is 7-8 days to most locations in India from our Bengaluru warehouse. Express shipping available for urgent orders.
Do you provide technical support?
Yes! Our expert team provides 24/7 technical support via Email and WhatsApp. We help with circuit design, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only with full refund or replacement. applicable on manufacturing defects only. Simply contact our support team with photos of the defect.
Are bulk discounts available?
Yes! Wholesale pricing is available on orders of 10 or more units. Contact us for custom quotes.
Can I use this IC with 3.3V logic systems?
The 74HC245 operates in the 2V-6V range and is compatible with 3.3V systems. However, for strict 3.3V applications, consider the 74LVC245 variant. Consult our team for your specific use case.
What's the maximum data transfer speed?
The 74HC245 supports high-speed CMOS operation. Typical propagation delay is ~10-15ns. Check the datasheet for exact specifications based on your supply voltage.
Technical Resources
- Datasheet: Available in PDF format
- Application Circuits: Example schematics provided
- Design Guide: Best practices for bus transceiver implementation
