Control high-voltage appliances safely from your microcontroller with this 1-Channel 5V Optocoupler Relay Board. The built-in optocoupler provides complete electrical isolation between your low-voltage control circuit (Arduino, Raspberry Pi, ESP32) and the high-voltage load side, protecting your sensitive electronics from voltage spikes and back-EMF. Ideal for home automation, IoT switching, and industrial control projects. Available at The Tech Depot, Bengaluru with fast shipping and full technical support.
Specifications
| Channels | 1 Channel |
| Control Voltage | 5V DC (TTL Logic Compatible) |
| Trigger Type | Active Low (Low-level trigger) |
| Isolation | Optocoupler isolated (input-output electrical separation) |
| Relay Type | SPDT (Single Pole Double Throw) - NO, NC, COM terminals |
| Relay Rated Load | 10A @ 250V AC / 10A @ 30V DC (maximum) |
| Coil Voltage | 5V DC |
| Input Signal Current | ~15-20 mA |
| Switching Time | ~10 ms (typical) |
| Relay Mechanical Life | ~100,000 operations |
| Indicator LEDs | Power LED + Relay Status LED |
| Board Dimensions | ~50 x 26 x 18.5 mm (approx.) |
| Mounting | Screw holes for secure panel/chassis mounting |
| Connector - Input | 3-pin header (VCC, GND, IN) |
| Connector - Output | Screw terminal block (NO, COM, NC) |
| Compatible Platforms | Arduino, Raspberry Pi, ESP8266, ESP32, STM32, PIC, 8051, NodeMCU |
| Operating Temperature | -25 degreesC to +70 degreesC |
| Type | Relay & Switching Module |
| Origin | Original/Authentic |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Key Features
- Optocoupler Isolation: Completely separates the microcontroller side from the relay coil and high-voltage load, preventing ground loops, noise, and dangerous voltage feedback
- Active Low Trigger: Relay activates when the input signal is pulled LOW, compatible with most microcontroller GPIO pins and open-collector outputs
- High-Current Switching: Handles loads up to 10A at 250V AC or 30V DC - enough for lights, fans, motors, pumps, solenoid valves, and heaters
- SPDT Relay Output: Three-terminal screw block (NO, NC, COM) allows both normally-open and normally-closed configurations for flexible circuit design
- Dual Status LEDs: Onboard power indicator and relay activation LED provide instant visual confirmation of board status and switching state
- Screw Terminal Output: Secure, vibration-resistant connections for high-voltage wiring - no soldering needed on the load side
- Standard Pin Header Input: 3-pin header (VCC, GND, IN) for quick breadboard prototyping or direct jumper wire connection
- Compact Single-Channel Design: Small footprint perfect for projects requiring just one switching channel without wasting board space
- Mounting Holes: Pre-drilled holes for secure screw mounting inside enclosures, control panels, or DIN rail setups
- Wide Platform Compatibility: Works seamlessly with Arduino Uno/Mega/Nano, Raspberry Pi, ESP8266, ESP32, NodeMCU, STM32, and virtually any 5V logic microcontroller
Why Choose This?
- 100% authentic from trusted suppliers - quality-tested relay and optocoupler components
- 1-5 day shipping, 7-8 day delivery from Bengaluru warehouse across India
- Expert technical support included for wiring, code, and integration help
- Optocoupler isolation adds a critical safety layer absent in basic relay modules
- Battle-tested design used in thousands of home automation and IoT projects worldwide
How It Works
- Input Side: Connect VCC to 5V, GND to ground, and IN to a digital GPIO pin on your microcontroller
- Optocoupler Stage: When IN goes LOW, current flows through the optocoupler LED, which triggers the phototransistor on the isolated side - no electrical connection crosses the barrier
- Relay Activation: The phototransistor output drives a transistor that energizes the relay coil, mechanically
