12V DC 1/2″ Electric Solenoid Water Air Valve Switch (Normally Closed)
12V DC 1/2″ Electric Solenoid Water Air Valve Switch (Normally Closed)
Shipping calculated at checkout.
Looking to buy 12V DC 1/2″ Electric Solenoid Water Air Valve Switch (Normally Closed) at the best price in India? Tech Depot India offers competitive pricing, bulk discounts for orders of 10+ units, and dedicated technical support via email and WhatsApp. Whether you are a hobbyist, student, or professional engineer, we have everything you need for your electronics projects.
12V DC 1/2 Electric Solenoid Water Air Valve Switch (Normally Closed)
12V DC Solenoid Water Air Valve Switch(Normally Closed)1/2 controls the flow of fluid (liquid or air) and acts as a valve between high-pressure fluid! This liquid valve would make a great addition to your robotic gardening project.There are two (Nominal NPT) outlets.Normally, the valve is closed. When a 12V DC supply is applied to the two terminals, the valve opens and water can push through.
The valve works with the solenoid coil which operates electronically with DC 12 volt supply. As it is a normally closed assembly,it opens the flow of fluids as soon as it is powered ON and stops/blocks the flow when the supply voltage removed.
Note: While Connecting Valve in Flow pipeline, you need to mind the Input and Output direction of the valve. It will work only if you connect it in the right direction. (Hint:Inside the value, at one side you will find the filter this is the input side of the value). It is not suitable for use with Gravity fed systems
Specifications
| Model | 12V DC 1/2" Solenoid Valve |
| Rated Operating Voltage (VDC) | 12 |
| Rated Current (mA) | 600 |
| Operation Mode | Normally Closed |
| Power Consumption (Watt) | 8 |
| Pressure | 0.02- 0.8Mpa |
| Energized forms | Intermittent |
| Inlet and outlet Diameter | Hose barbs for 1/2" (outer diameter) hose |
| Dimensions (mm) LxWxH | Body: 84 x 57mm (L x H) |
| Weight (gm) | 100 |
| Max fluid temperature | 100C |
Why Choose 12V DC 1/2″ Electric Solenoid Water Air Valve Switch (Normally Closed)?
100% Authentic
GST Invoice - A GST invoice is included with every order.
Expert Support - Dedicated technical help on WhatsApp and email.
Pan-India Delivery - Shipped across Bengaluru, Delhi NCR, Hyderabad and all of India.
Trusted by Makers - Used by students, hobbyists and professionals nationwide.
Key Features of 12V DC 1/2″ Electric Solenoid Water Air Valve Switch (Normally Closed)
- Compact and convenient.
- Easily installed and serviced
- Precise and reliable.
- The installation direction can be arbitrary Angle
- Pressure-regulating valve (steady flow valve) function similar to the water flow switch
- Not only can it provide a steady flow, but it also prevents the dry burning.
- Suitable for fluids like water, oil, air.
Package Includes:
1 x 12V Solenoid Water Air Valve Switch (Normally Closed) 1/2
Frequently Asked Questions
When will I receive my order?
Is technical support available?
Yes, responsive support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
Customer Support
Email: techdepotindia@gmail.com
WhatsApp: Available for setup and troubleshooting help
Order your 12V DC 1/2″ Electric Solenoid Water Air Valve Switch (Normally Closed) today and start building your next project.
